| Ukuran (HxWxD) | 176mm x 138mm x 28mm |
| Bobot | <500g |
| Suhu operasi | 0 ℃ ~ + 40 ℃ |
| Kelembapan operasi | 5% RH ~ 95% RH, (non-kondensasi) |
| Input adaptor daya | 150V～264V AC, 50Hz～ 60Hz |
| Sumber daya sistem | 11V ~ 14V DC, 1A |
| konsumsi daya statis | 4.5W |
| konsumsi daya maksimum | 12W |
| Pelabuhan | 1POTS +4FE +Wi-Fi+USB |
| Indikator | POWER/PON/LOS/LAN/TEL/USB/WLAN/WPS |
Port GPON Kab
● Kelas B+
● Sensitivitas panrima:-27dBm
● Dawane gelombang: US 1310nm, DS 1490nm
● WBF
● pemetaan fleksibel antarane GEM Port lan TCONT
● GPON:konsisten karo SN utawa otentikasi sandi sing ditetepake ing G.984.3
● Dwi-arah FEC
● SR-DBA lan NSR-DBA
Port Ethernet
● tag VLAN basis port Ethernet lan mbusak tag
● 1:1 VLAN, N: 1VLAN, utawa VLAN transmisi transparan
● QinQ VLAN
● Watesan jumlah alamat MAC sing disinaoni
● sinau alamat MAC
Port POTS
● REN maksimum:4
● G.711A/μ, G.729a/b, lan G.722 encoding/decoding
● mode faks T30/T.38/G.711
● DTMF
● Telpon darurat (karo protokol SIP)
WLAN
● IEEE 802.11 b/g/n
● 2×2 MIMO
● gain antena: 2 dBi
● WMM
● Multiple sSIDs
● WPS
Port USB
● USB2.0
● panyimpenan jaringan basis FTP
Interkoneksi cerdas
● Cakupan Wi-F cerdas (V300R015C10)
● SIP / H.248otomatis rembugan
● Sembarang layanan portany
● Parentalcontrol (V300R015C00)
Layanan pinter
● Smart Wi-Fisharing:
Portal, otentikasi 802.1x (V300R015C10) Nuduhake basis GRE alus (V300R015C10)
● Akun siji
Pinter O&M
● Diagnosis kualitas video IPTV (V300R015C10)
● Pesen OMCI dawa variabel
● Aktif / Pasif deteksi ONT nakal lan isolasi
● Telpon emulation, lan circuittest lan loop-line test
● Pengujian simulasi PPPoE/DHCP. emulasi WLAN
Layer 3 Fitur
● PPPoE/Static IP/DHCP
● NAT/NAPT
● Port forwarding
● ALG,UPnP
● DDNS/DN Sserver/Klien DNS
● IPv6/Pv4 dual tumpukan, lan DS-Lite
● Rute statis/Default
● Multipleservices ing siji port WAN
Multicast
● IGMP v2/v3 snooping
● proxy IGMPv2
● IGMP v3 proxy(V300R015C00)
● MLD v1/v2 snooping
● Layanan multicast liwat Wi-Fi
Qos
Ethernet port ratelimitation
● prioritas 802.1p
● SP/WRR/SP+WRR
Pembatasan tarif paket siaran
Keamanan
● SPI firewall
● Nyaring adhedhasar alamat MAC/IP/URL
O&M umum
● OMCI/Web UI/TR069
● Gawe serep lan muter maneh piranti lunak sistem dual
Ngirit daya
● Ngirit daya dinamis
● Ngirit daya indikator
● Wi-Fi sing dijadwalake mateni (V300R015C00)
