TENKILOMETERS kualitas dhuwur HS8145C Single Band XPON ONU ONT punika Kapabilitas maju-kinerja dhuwur, iku njamin pengalaman pangguna ngédap kanggo VoIP, Internet, lan layanan video HD. Iki solusi terminal sing cocog, nyedhiyakake dhukungan layanan sing siap ing mangsa ngarep kanggo panyebaran FTTH.
|
Item teknis |
Katrangan |
|
Out Port ngemot |
1GE+3FE+1POT+1UB+WiFi |
|
sinyal WIFI |
2.4G WiFi |
|
Keuntungan nirkabel |
2db |
|
USB |
2.0 |
|
LAN |
1*10/100/1000Mbps port Ethernet adaptif, full/half duplex, antarmuka RJ45 |
|
TEL |
H248/SIP Swara Protokol |
|
Jembatan PPPOE |
Dhukungan |
|
Firmware |
Inggris |
|
Ukuran / bobot |
153mm * 125mm * 32mm / 176g |
|
port serat |
1 antarmuka GPON/EPON, serat ingle, tingkat Hilir 2.5Gbps, Tingkat hulu 1.25Gbps |
|
Dawane gelombang |
Tx 1310nm, Rx 1490nm |
|
Antarmuka serat |
SC/UPC/APC Singal mode |
|
sensitivitas RX |
>-28dBm (1490nm) |
|
daya DC |
12V 1A, adaptor daya AC-DC eksternal |
|
Tombol |
Reset, Daya, Wlan, Wps |
|
Operasi |
Suhu kerja: -5- + 55 ℃ kelembaban kerja: 10-90% (non-kondensasi) |
|
Panyimpenan |
Suhu panyimpenan: -30 ℃ - + 60 ℃ asor panyimpenan: 10-90% (non-kondensasi) |
1. Plug-and-Play:Gampang nyebarake layanan kanthi klik siji ing NMS, ngilangi kabutuhan konfigurasi ing situs.
2. Diagnosis Jarak Jauh:Deteksi kesalahan adoh liwat tes loop-line port POTS, emulasi panggilan, lan emulasi dial-up PPPoE.
3.Pengawasan Link:Entuk deteksi link end-to-end kanthi 802.1ag Ethernet OAM, njamin stabilitas jaringan.
4. Terusake kacepetan dhuwur:Ngalami 900 Mbit/s nerusake ing skenario NAT, njamin transmisi data cepet.
5. Kapabilitas IPv6:Ndhukung IPv6/IPv4 dual stack lan DS-Lite, njamin kompatibilitas karo standar jaringan modern.
