TENKILOMETERS kualitas dhuwur EN8145X6 DUAL BAND WIFI6 XG-PON ONU ONT FTTH unit nawakake akses ultra-broadband, kinerja dhuwur, lan jangkoan sudhut kanggo pelanggan. Kanthi kinerja penerusan sing dhuwur, EN8145X6 njamin pengalaman kualitas dhuwur kanggo layanan swara lan data - plus kapabilitas dhukungan layanan berorientasi mangsa ngarep - OptiXstar EN8145X6 mbantu perusahaan masang solusi akses optik kabeh sing kompetitif.
|
Model |
EN8145X6 |
|
Pelabuhan |
4 x GE, 1 x POTS, 1 x USB, 2.4G/5G Wi-Fi 6 |
|
Jinis |
XG-PON |
|
Ukuran (L x W x H) |
40 x 185 x 120 mm (tanpa antena lan bantalan eksternal) |
|
Bobot (Tanpa Adaptor Daya) |
Kira-kira 400 g |
|
Suhu operasi |
0–40°C |
|
Kelembapan Operasi |
5–95% RH (non-kondensasi) |
|
Input Adaptor Daya |
100–240 V AC, 50/60 Hz |
|
Sistem Power Supply |
11-14 V DC, 1,5 A |
|
Konsumsi Daya Maksimum |
18 W |
|
Antena |
Antena njaba |
|
Mode Instalasi |
Desktop |
|
Ngirit daya |
COC V7 |
|
Port USB |
USB 2.0 |
|
panyimpenan jaringan basis FTP |
|
|
Enggo bareng file/Cetak adhedhasar SAMBA |
|
|
Fungsi DLNA |
SC/UPC
DTMF
WPA3
QinQ VLAN
Kelas N1/N2a/E1
Sensitivitas panrima: -28 dBm
FEC hulu lan hilir
SR-DBA lan NSR-DBA
sinau alamat MAC
Kacepetan port otomatis (10/100/1000 Mbit/s)
RUN maksimum: 4
Mode faks T.30/T.38/G.711
Telpon darurat (karo protokol SIP)
IEEE 802.11 b/g/n/ax (2.4G)
IEEE 802.11 a/n/ac/ax (5G)
2 x 2 MIMO (2.4G)
2 x 2 MIMO (5G)
gain antena: 5 dBi
WMM / Multiple SSIDs / WPS
2.4G lan 5G concurrency
Beamforming
Band setir
DL OFDMA
DL MU-MIMO
1024 KAB
Bandwidth frekuensi 160 MHz
Filter Pemblokiran Panjang Gelombang (WBF)
Dawane gelombang: US 1260–1280 nm, DS 1575–1580 nm
Pemetaan fleksibel antarane port GEM lan TCONT
Tingkat antarmuka udara: 574 Mbit/s (2.4G), 2.402 Gbit/s (5G)
2,5 Gbit/s hulu, 10 Gbit/s hilir
G.711A/μ, G.729a/b lan G.722 encoding/decoding
Tag VLAN basis port Ethernet lan mbusak tag
1: 1 VLAN, N: 1 VLAN, utawa transmisi transparan VLAN
Watesan jumlah alamat MAC sing dipelajari
SN/Sandi/SN + Sandi/Bi-directional otentikasi adhedhasar OMCI
