HN8145X6 DUAL BAND WIFI6 XG-PON ONU ONT FTTH minangka Wi-Fi 6 routing-type 10G Optical Network Terminal kanthi 4 port GE, 1 port POTS, lan 2 port USB, lan konektivitas Wi-Fi 2.4G lan 5G. HN8145X6 nganggo teknologi Gigabit Passive Optical Network (GPON) kanggo nawakake akses ultra-broadband, kinerja dhuwur, lan jangkoan sing amba kanggo pangguna, njamin pengalaman sing luar biasa kanggo layanan video swara, data, lan High Definition (HD) lan kapabilitas dhukungan layanan berorientasi ing mangsa ngarep. lan manajemen jaringan visualized, Mulane, Huawei HN8145X6 10G FTTH ndhukung Enterprises mbangun solusi akses kabeh-optik kuat.
|
Item |
HN8145X6 |
|
Port sisih jaringan |
GPON/EPON |
|
Port sisih pangguna |
4*GE+1*POTS+2*USB+2.4G/5G WiFi 11ax (Wi-Fi 6) |
|
konsumsi daya statis |
5.3 W |
|
Maks. konsumsi daya |
18 W |
|
WLAN |
2.4GHZ: 802.11n 5GHZ: 802.11ax |
|
Spesifikasi daya |
Input adaptor daya: 100 nganti 240 V AC, 50–60 Hz Sumber daya sistem: 11–14 V DC, 1,5 A |
|
Indikator |
POWER/PON/LOS/TEL/LAN/WLAN/WPS/USB |
|
Lingkungan kerja |
Suhu operasi: 0ºC nganti 40ºC Kelembapan lingkungan: 5% nganti 95% (nonkondensasi) |
|
Ukuran (dawa x lebar x dhuwur) |
195 mm x 125 mm x 35 mm |
|
Bobot |
Kira-kira 370 g |
Sensitivitas panrima: -27 dBm nganti -29 dB
Daya optik kakehan: –8 dBm
Dawane gelombang: US 1310 nm, DS 1490 nm
Wavelength Blocking Filter (WBF) saka G.984.5
Pemetaan fleksibel antarane port GEM lan TCONT
GPON: konsisten karo SN utawa sandi bukti asli ditetepake ing G.984.3
SR-DBA lan NSR-DBA
Tipe B (single-homing lan dual-homing)
Tag VLAN basis port Ethernet lan mbusak tag
1: 1 VLAN, N: 1 VLAN, utawa transmisi transparan VLAN
QinQ VLAN
Watesan jumlah alamat MAC sing dipelajari
sinau alamat MAC
Kacepetan port otomatis (10/100/1000 Mbit/s)
RUN maksimum: 4
711A/μ, G.729a/b, lan G.722 encoding/decoding
30/T.38/G.711 mode faks
Telpon darurat (karo protokol SIP)
